Resin Liquid Mixing Reactors

1. Product Function Brief of Industrial heated jacket tank/reactor

1). Operating principle: Break down or recombined the materials through mixing, filling and cooling, to promote the reaction of polymerization.

2). Components: Body, gears, mixing devices, heating devices, cooling devices, seal, etc.

3). Auxiliary Equipment: Distillation column, head tank, condenser, water separator, collecting cans, filters, etc..

4). Widely used in: Resins, adhesives, paint, cosmetics, pharmaceutical and other chemical production.

5). Applicable Field: All the liquid-liquid, liquid-powder reaction industry.

2. Instruction

1). Reactor kettle is the main chemical react production equipment, which is widely used in resins, adhesives, paint, cosmetics, pharmaceutical and other chemical production.

2). Break down or Re-combined the molecule through mixing, Heating, cooling, Vacuumize, etc. Suit for polymerization, hydrogenation, vulcanization, nitration,etc. The reactor is made up of body vessel, jacket vessel, gears, mixing devices, heating devices, cooling devices, seal composition,etc.
3. Model selection reference of Automatic heated jacket tank/reaction kettle

Composition

Instructions

Specification (L)

50-50000

Design Pressure (Mpa)

Atmospheric Pressure or under pressure

Material

Carbon steel, stainless steel, enamel, graphite

Heating Forms

Electrical heating with medium in jacket, external half coil steam heating,

external half conduction oil heating, hot water infrared heating etc.

Cooling Forms

Refrigeration medium in the internal pipe jacket

Blending Power

Model selection is made according to material viscosity, liquid-solid ratio, liquid specific gravity, solid specific gravity, solid granularity,

rotation speed, paddle type, with or without baffle or internal coil.

Stirring blade Forms

Anchor type, frame type, flat paddle type, pitched paddle type, ribbon

type, turbo type, pusher type and multiple compound type

Seal

Mechanical seal or stuff packing seal

Inner Surface Treatment

Polished or no polished

Discharge Valve

Flanged ball valve, open downward discharge valve and others

Technological Pipe Hole

Manhole, sight glass, distillation mouth, imported materials, pressure

gauge port, temperature, mouth, mouth filling N2.
